ASUS PRIME H610M-K D4 Intel LGA1700 Micro-ATX Motherboard

Starting from

€57.28● 5 in stock

excl. VAT · incl. VAT: €69.31

From €57.28

Description

Micro-ATX Intel H610 motherboard for LGA1700 (12th Gen Intel Core). 2x DDR4 DIMM slots, up to 64GB. 1x PCIe 4.0 x16, 1x M.2. Outputs: VGA, HDMI 2.1. Gigabit Ethernet. USB 3.2 Gen1. UEFI BIOS. 5x Protection III.

GENERAL
Manufacturer	ASUS
Condition	New
SKU	1358850
DETAILS
Chipset	Intel H610
Form factor	micro ATX
RAM slots	2
Socket	LGA 1700
Wi-Fi	No
12v power connector	Yes
Atx power connector (24 pin)	Yes
Audio output channels	7.1
BIOS memory size	128
BIOS type	UEFI AMI
Cables included	SATA
Category code	MBI
Chipset vendor	Intel
Compatible processor series	Intel® Celeron®/Intel® Core™ i3/Intel® Core™ i5/Intel® Core™ i7/Intel® Core™ i9/
Component for	PC
CPU fan connector	Yes
Depth	203
Description	<p>ASUS Prime series motherboards are expertly engineered to unleash the full po
Display outputs	VGA, HDMI 2.1
Drivers included	Yes
ECC сompatibility	Non-ECC
Eps power connector (8 pin)	Yes
Ethernet interface type	Gigabit Ethernet
Ethernet LAN	Yes
Ethernet LAN (rj 45) ports	1
Front panel audio connector	Yes
Harmonized system (hs) code	84733020
HDMI ports quantity	1
HDMI version	2.1
Headphone outputs	1
Height	51
LAN	Gigabit Ethernet
M2 slots	1
Max ram	64 GB
Maximum number of smp processors	1
Memory channels	Dual-channel
Memory slots type	DIMM
Microphone in	Yes
Number of chassis fan connectors	1
Number of com connectors	1
Number of displays supported	2
Number of m.2 (m) slots	1
Number of SATA iii connectors	4
PCI express x16 (gen 3.x) slots	1
PCI express x16 (gen 4.x) slots	1
PCIE x16 slots	1
Processor manufacturer	Intel
Ps/2 ports quantity	1
RAID	0,1,5,10
RAID levels	0/1/10/5
Ram max	64
Ram type	DDR4
RGB LED pin header	Yes
S/pdif out connector	Yes
Summary	ASUS PRIME H610M-K D4. Processor manufacturer: Intel, Processor socket: LGA 1700
Supported memory clock speeds	2133/2400/2666/2800/2933/3000/3200
Supported memory types	DDR4-SDRAM
Supported storage drive interfaces	M.2,SATA
Supported storage drive types	HDD & SSD
Tpm connector	Yes
Unbuffered memory	Yes
Unit box height	0.26
Unit box length	0.27
Unit box width	0.055
Unit calculated volume	0.004788
Unit calculated weight	0.99
Units per pallet	0
Units per shipping box	10
USB 2.0 connectors	1
USB 2.0 ports quantity	4
USB 3.2 gen 1 (3.1 gen 1) connectors	1
USB 3.2 gen 1 (3.1 gen 1) type a ports quantity	2
Vendor homepage	https://www.asus.com/Motherboards-Components/Motherboards/PRIME/PRIME-H610M-K-D4
Vga (d sub) ports quantity	1
Weight	842
Wi fi	No
Width	234
Windows operating systems supported	Windows 10 x64/Windows 11 x64
